UKPA - F Seal Tapered Bore Bearings
Heavy Duty Housing
UK F Seal Tapered Bore
Bearings
HIGH temperature
HIGH RPM
Product Detail
204 To 218 Series
Metric Bore Size : 20MM - 80MM | Inch Bore Sise : 3/4 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
UKPA 200 Industrial Tapered Bore For Use With Adapter Sleeve Locking Series Cast-Iron Tapped Base Plummer Block Housed Units
- UKPA bearings are used across several major machinery sectors due to their narrow profile and robust mounting profile
- UKPA bearings are short-base pillow block bearing units specifically designed for applications with tight spatial limitations and requirements for fast, reliable shaft mounting.
- Both Japanese Standards and American Standards are available. See in our full bearing catalogue
- UKPA housing has tapped holes in base instead of through-holes. Mounts from bottom.
- Preci-Max(PMX) UKPA series housed units feature the Preci-Max(PMX) tapered bore(UK)bearing insert for use with adapter sleeve
