UCPA - F Seal Bearings
Heavy Duty Housing
F Seal
Bearings
HIGH temperature
HIGH RPM
Product Detail
201 To 218 Series
Metric Bore Size : 12MM - 90MM | Inch Bore Sise : 1/2 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
Cast-Iron Plummer Block Housing Units
UCPA Industrial Series
- UCPA Plummer block housing units ensure accurate mounting fits and provide better support for heavy loads.
- Each unit comes assembled and ready for mounting, using bolts through the flange.
- These units use wide inner ring ball bearings with self-aligning spherical outside diameters that compensate for shaft misalignment.
- Bolt-hole specing dimensions and shaft center location are interchangeable with competitive units.
- Preci-Max UCPA-series set screw flanged units feature the Preci-Max UC bearing insert.
- Bearing prelubricated and ready for immediate installation.
- Grease fitting supplied for relubrication.
- The F seal design in well-suited for industrial applications involving wet or dirty environments.
- Housing design for ease of bearing replacement
