UKT - F Seal Tapered Bore Bearings
Heavy Duty Housing
UK F Seal Tapered Bore
Bearings
HIGH temperature
HIGH RPM
Product Detail
204 To 218 Series
Metric Bore Size : 20MM - 80MM | Inch Bore Sise : 3/4 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
UKT 200 Industrial Tapered Bore For Use With Adapter Sleeve Locking Series Cast-Iron Take-Up Housed Units
- UKT Bearing is widely used in various applications due to their versatility and reliability. Common applications include agricultural machinery, textile, printing, construction, conveyor systems, fans, and automotive parts. UKT bearings can provide precise motion control and support under radial loads.
- The design of UKT Bearing allows for easy mounting and alignment, suitable for a broad range of industrial and commercial uses.
- Both Japanese Standards and American Standards are available. See in our full bearing catalogue UKT take-up units are used where shaft adjustment and belt-tightening devices are required, such as in conveyor applications.
- Preci-Max(PMX) UKT series housed units feature the Preci-Max(PMX) tapered bore(UK)bearing insert for use with adapter sleeve
