UKP - Pillow Block Units
Heavy Duty Housing
UK F Seal Tapered Bore
Bearings
HIGH temperature
HIGH RPM
Product Detail
204 To 218 Series
Metric Bore Size : 20MM - 80MM | Inch Bore Sise : 3/4 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
UKP 200 Industrial Tapered Bore For Use With Adapter Sleeve Locking Series Cast-Iron Pillow Block Housed Units
UCP Industrial Series
- UKP Bearing is widely used in various applications due to their versatility and reliability. Common applications include
- agricultural machinery, textile, printing, construction, conveyor systems, fans, and automotive parts. UKP bearings can provide precise motion control and support under radial loads.
- The design of UKP bearing allows for easy mounting and alignment, suitable for a broad range of industrial and commercial uses.
- Both Japanese Standards and American Standards are available. See in our full bearing catalogue.
- UKP pillow block are suggested for heavy-duty industrial applications with high loads & vibration.
- Preci-Max(PMX) UKP series housed units feature the Preci-Max(PMX) tapered bore(UK)bearing insert for use with adapter sleeve
