UKHB - F Seal Tapered Bore Bearings
Heavy Duty Housing
UK F Seal Tapered Bore
Bearings
HIGH temperature
HIGH RPM
Product Detail
204 To 218 Series
Metric Bore Size : 20MM - 80MM | Inch Bore Sise : 3/4 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
UKHB 200 Industrial Tapered Bore For Use With Adapter Sleeve Locking Series Cast-Iron Hanger Housed Units
UCP Industrial Series
- UKHB bearings—specifically known as UK-type Hanger Bearings—are specialized mounted bearing units utilized primarily in screw conveyor systems, material handling machinery agricultural equipment where suspended drive shafts require reliable mid-span support. The "UK" prefix designates that the insert ball bearing features a tapered bore, which relies on an external adapter sleeve (such as an H-series sleeve) to clamp tightly onto standard straight shafts
- These units are designed to withstand challenging environments, preventing long mechanical shafts from sagging or deflecting under radial loads.
- Both Japanese Standards and American Standards are available. See in our full bearing catalogue
- Screw Conveyors: Mounted internally within the conveyor trough to support the middle segments of long auger screw flights.
- Preci-Max (PMX) UKHB series housed units feature the Preci-Max(PMX) tapered bore(UK)bearing insert for use with adapter sleeve
