UK - F Seal Tapered Bore Bearings
Heavy Duty Housing
UK F Seal Tapered Bore
Bearings
HIGH temperature
HIGH RPM
Product Detail
204 To 218 Series
Metric Bore Size : 20MM - 80MM | Inch Bore Sise : 3/4 Inch - 3 inch
| Bearing | |
|---|---|
| Make | PRECI-MAX® [PMX™] |
| Material | 100 CR6/SAE 52100 Imported |
| Rpm | 1400 to 4000 RPM |
| Seal Type | F Seal (White) Metal |
| Ball Grade Quality | G10 Q |
| Quality | P0 100% ZV1 |
| Grease Operating Temperature | -30° ~ 180° C |
| Grease Dropping Point | 290° C |
| Seal Quality | Temperature and Water Resistant with Proper Fitment |
| Housing | |
|---|---|
| Weight | Heavy Duty |
| Material Grade | FG200 |
| Hardness | 160 to 170 HB |
| Material Process | Induction Casting, Greensand |
| Colour | Grey/powder Coated |
| Face | VMC/CNC Turning |
| Grease Nipple Size | M6 X 1, M8 X 1 |
| Grease Nipple Material | MS |
| Grease Nipple Cap Material | Virgin Red Colour |
UK 200 Industrial Tapered Bore For Use With Adapter Sleeve Locking Series Wide Inner Ring Ball Bearings
- UK Bearing is widely used in various applications due to their versatility and reliability. Common applications include agricultural machinery, textile, printing, construction, conveyor systems, fans, and automotive parts. UK bearings can provide precise motion control and support under radial loads.
- The design of UK bearing allows for easy mounting and alignment, suitable for a broad range of industrial and commercial uses. Metric Standard see our UK bearing in our full bearing catalogue.
- The UK tapered bore wide inner ring ball bearing uses an adapter sleeve locking mechanism and is suggested for industrial applications where normal loads are encountered
- The adapter locking feature is used in applications where the bearings are exposed to excessive vibration and impact.
- Adapter locking results in high concentricity.
- Adapter locking prevents fretting corrosion under adverse conditions. • Bearing prelubricated and ready for immediate installation. The wide inner ring provides effective shaft support for a broad range of industrial applications.
- An external steel flinger provides additional protection from contamination.
- UK series wide inner ring ball bearings have spherical outside diameters for use in housings with corresponding spherical inside surfaces to compensate for shaft misalignment.
